Extruded Rubber Profile

Name: Extruded Rubber Profile
Brand: TECHNOSEAL ENGINEERING
Price: 10 INR
Availability: InStock

10 INR/Piece

Get a Price/Quote

Product Details:

Width 10 mm to 100 mm (custom sizes available)
Product Type Extruded Rubber Profile
Diameter 1/2 inch to 26 Inch (in)
Natural Rubber Available or can be custom blended
Tolerance 0.2 mm
Thermal Conductivity < 0.25 W/mK
Weight Varies by profile and material
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Extruded Rubber Profile Price And Quantity

Minimum Order Quantity 10 Piece
Price 10 INR/Piece

Shape Options D, P, U, L, E, Square, Custom
Shelf Life Up to 5 years (recommended in cool, dry storage)
Ozone Resistance Excellent for EPDM
Installation Easy press-fit or adhesive
Adhesive Backing Available upon request
RoHS Compliance Yes
Customization Profiles, colors, hardness, material blends
Shore Hardness Range 40A to 80A
Elongation at Break 250% - 400%
UV Stability High
Specific Gravity 1.20 to 1.55

Extruded Rubber Profile Product Specifications

Compression Ratio 10-30% (typical depending on material and profile)
Density 1.2 Gram per cubic centimeter(g/cm3)
Hardness 40 to 80 Shore A
Volatile Matter (%) < 2.5%
Part Type Extruded Profile
Color Black (other colors available upon request)
Rubber Type EPDM, Neoprene, Nitrile, Silicone, SBR, Natural Rubber
Ash % < 5%
Length Standard or custom cut lengths
Size Customizable as per requirement
Feature Flexible, Weather Resistant, Ozone Resistant, Durable
Style Solid, Sponge, or Customized profiles
Temperature Resistance -40C to +120C (EPDM); up to 200C (Silicone)
Resistance level High resistance to aging, UV, ozone, and weather
Tensile Strength 10-15 MPa
Flame Resistance Level Available as per requirement (e.g., UL94 standards)
Thickness 2 mm to 25 mm
Surface Finish Smooth/Matte/Custom
Weight Varies by profile and material
Tolerance 0.2 mm
Thermal Conductivity < 0.25 W/mK
Natural Rubber Available or can be custom blended
Diameter 1/2 inch to 26 Inch (in)
Product Type Extruded Rubber Profile
Width 10 mm to 100 mm (custom sizes available)
Usage & Applications Sealing, insulation, vibration dampening, automotive, construction, electrical enclosures, window/door frames
Components Single or multi-component
Water Absorption Low
Material EPDM, Nitrile, Neoprene, Silicone, Natural Rubber, SBR
Nitrogen Content (%) < 1.0%

Shape Options D, P, U, L, E, Square, Custom
Shelf Life Up to 5 years (recommended in cool, dry storage)
Ozone Resistance Excellent for EPDM
Installation Easy press-fit or adhesive
Adhesive Backing Available upon request
RoHS Compliance Yes
Customization Profiles, colors, hardness, material blends
Shore Hardness Range 40A to 80A
Elongation at Break 250% - 400%
UV Stability High
Specific Gravity 1.20 to 1.55

Extruded Rubber Profile Trade Information

Payment Terms Cheque
Supply Ability 1000 Piece Per Day
Delivery Time 1 Week
Sample Available Yes
Sample Policy Free samples are available
Packaging Details carton
Main Export Market(s) Central America, Middle East, Asia, Australia, North America, South America, Eastern Europe, Western Europe, Africa
Main Domestic Market All India

Product Description

We are successfully engaged in offering a qualitative range of Extruded Rubber Profile that is used in different applications such as sealing, noise control, vibration and decorative trim. It seals the door with the door flange firmly to avoid dust, water & air to leak inside the cabin. We offer this Extruded Rubber Profile at affordable prices to clients. The increasing demand of this rubber profile in the market remains directly attributable to its heat resistance and easy installation.

Versatile Rubber Profiles for Every Industry

Our extruded rubber profiles offer remarkable flexibility and a wide range of customization options to suit multiple industry requirements. Whether you need robust weather resistance for outdoor installations or compliant solutions for electrical enclosures, these profiles provide a dependable seal and insulation across diverse applications. Their high durability and adaptability make them a preferred choice for automotive, construction, and industrial projects.

Custom Sizing and Multiple Material Choices

Select from various shapes and sizes, from 1/2 inch up to 26 inches in diameter, with widths from 10 mm to 100 mm and thicknesses between 2 mm and 25 mm. Our rubber profiles are available in EPDM, Nitrile, Neoprene, Silicone, SBR, or Natural Rubber and can be tailored to your desired profile, hardness, color, or surface finish, offering maximum adaptability to project specifications.

Effortless Installation and Superior Longevity

Installation is quick and convenient-choose from press-fit designs or adhesive-backed options. High-quality material formulations ensure longevity, resisting weather, aging, UV, and ozone exposure for up to five years (with proper storage). These profiles require minimal maintenance and retain their sealing and insulation properties even under challenging conditions.

FAQ's of Extruded Rubber Profile:

Q: How are extruded rubber profiles installed?

A: Our extruded rubber profiles can be easily installed by press-fit into grooves or channels, or by using adhesive backing for more permanent fixation. The installation method depends on your application requirements and profile type.

Q: What materials are used in these rubber profiles, and which should I select?

A: We manufacture profiles using EPDM, Nitrile, Neoprene, Silicone, SBR, and Natural Rubber. The choice depends on specific needs: EPDM for excellent ozone/UV resistance, Nitrile for oil resistance, Silicone for high-temperature tolerance, and Natural Rubber for general flexibility and resilience.

Q: When should I consider customizing size, hardness, or color for my project?

A: Customization is ideal when standard options do not meet your specific application demands. Custom dimensions, Shore hardness, and colors ensure a precise fit, optimized performance, and aesthetic match for unique industrial or architectural designs.

Q: Where can extruded rubber profiles be applied effectively?

A: These profiles are extensively used in automotive door and window seals, construction joints, electrical enclosures, window and door frames, and machinery vibration dampening. Their versatility allows them to address diverse sealing and insulation challenges across various sectors.

Q: What is the process for ordering custom rubber profiles?

A: To order a custom profile, specify the required dimensions, material type, Shore hardness, color, and any special features like adhesive backing or flame resistance. Our team will review your specifications, recommend suitable options, and guide you from prototyping to final production.

Q: How do I benefit from the product's high resistance to ozone, aging, and weather?

A: Using profiles with excellent ozone, UV, and weather resistance ensures long-term reliability, reducing maintenance needs and replacement costs. These attributes make them highly suitable for outdoor and industrial settings where exposure to harsh elements is frequent.
